Features
- Cone-roof tanks
- Floating-roof tanks for crude oil
- LPG tanks with pressure
- Tanks for refinery and others.
- No transmission error with resolution of 1 mm thanks to digital transmission
- High reliability and conversion accuracy with ± 1mm
- Easy calibration by using an in-house counter for transmitter monitoring
- Easy expansion and replacement because of compatibility with the existing other TOKYO KEISO's level transmitters
- Connectable to the existing spot type and multipoint averaging temperature sensors
- Remote monitoring and control in combination with TOKYO KEISO's digital tank data receiving instruments.
- Continuous power supply 85 to 240 V AC 50/60 Hz for AC types
- Flameproof construction complying with TIIS d2G4 is standardized for all models
- Lightning protection circuit with much more increased safety than existing models is provided as standard
Short Specifications
| Model | DM4N-1 | DM4N-2 | DM4N-3 |
|---|---|---|---|
| Old Model | DM4-1 | DM4-2 | DM4-3 |
| Communication type | 1-way | 2-way | 1-way |
| Applicable level gauges | 1) FT-1000 series Spring balance type 2) FT-2000 series Servo balance type 3) FW-2200 series All wire servo balance type 4) FP-1000 series Magnet float type 5) Other manufacturers' tank side level gauges. Couplings are available. | ||
| Connectable receivers as examples | 1) CATAMS Tank monitoring system 2) NMR5000 series 3) DIR-530 series | ||
