TM-1400

คุณสมบัติสินค้า:

เปรียบเทียบ

แบรนด์ : TOKYO KEISO

Features

As small as DIN 72 square, light and space saving
Necessary functions for process control and management are integrated into one unit as standard:
Instantaneous flow rate indication and output, totalizing pulse output, and flow rate setting function
Easy operation as all parameters can be set at front panel

Short Specifications

Applicable flow controllers	TC-1000, TC-2000, TC-3000, EP-TC-1000/2000V
Input	Flow controller output: exclusive cable standard 2m, maximum 100m as an option
Setting	External setting: Either DC4 to 20mA, DC0 to 5V, DC1 to 5V is selectable. Manual setting: Switching to external or manual setting, or ratio setting to external input with 10 rotations analogue dial vernier and minimum graduation 1%.
Outputs	Analogue output: DC4 to 20 mA, Accuracy: ±0.1 % F.S. additional to detector accuracy DC0 to 5V, Accuracy: sensor accuracy Selectable either two case otalizing pulse output: Open collector pulse, Scaling factor 60 to 12000c/h F.S.
Zero adjustment	Zero adjustment trimmer
Power suppy	AC85 to 240V (50Hz/60Hz) 15VA
Installation	Panel mounted with DIN72 size
Enclosure	IP20 equivalent
