CLFC300

คุณสมบัติสินค้า:

Share

แบรนด์ : TOKYO KEISO

Share

Features

  • Improved flow measurement
    • Flow measurement is stabilized by faster calculation and improved bubble resistance.
  • Excellent controllability
    • A quick step response is achieved by state-of-the-art signal processing technology. The CLFC300 tracks variations in the flow and returns it to the set point within 1.5 seconds.
  • Two valves for wider applications
    • A needle valve is available for chemical liquids and DIW, and a pinch tube valve for slurry liquids. The STA-PURE style pcs tube is added to the lineup of pinch tubes. This tube has excellent durability and does not need to be replaced regularly.
  • Lightweight and compact
    • An ultrasonic flowmeter, a control valve, and a circuit are all contained in a single case. In addition, the layout was revised to make the controller more compact: it is now 20% smaller and 35% lighter.
  • Easy installation
    • No complicated piping or wiring is required: simply connect the fittings and multi-core cables to complete the installation.
  • Eco-friendly
    • Power consumption is reduced by 35%. All parts are comply with the RoHS requirements.
  • Corrosion-resistant
    • The CLFC uses highly-corrosion-resistant PFA and PTFE for wetted parts and ultra-durable PVDF for the case.
    • It is ideal for the semiconductor industry and other industries that use corrosive chemicals.
  • EMC-compliant
    • The controller conforms to EN 61326-1: 2006.


Applications

  • Constant feed of chemical liquids and DIW
    • The CLFC300 ensures accurate and stable feed control of chemical liquids and DIW, which was conventionally conducted by metering pumps and static head tanks.
  • Control of concentration
    • When CLFC300 are installed both in chemical liquids and pure water lines, they help directly dilute chemicals with pure water while controlling the concentration accurately and stably.
  • Constant feed of slurry
    • The CLFC300 on various slurry lines of CMP devices ensures stable and constant feed of slurry and saves valuable liquids.



Short Specifications

Measuring and
control objects
Liquids (No bubbles contained for stable measurement)
Measuring rangeMinimum: 5 to 50 mL/min
Maximum: 200 to 2000 mL/min
50 to 500 mL/min
Maximum operating
pressure
0.4 MPa
Operating temperature
range of fluid
10 to 50°C Consult Tokyo Keiso for the service more than 50°C
Process connectionSize: 1/4 inch
Type: Super 300 pillar fitting
Wetted partsPFA, PTFE
Output accuracyAdditional error for analog output: ±0.2% F.S.
Analog input /
output signal
One for set point signals and one for flow output signals
Set point/Flow out: 4 to 20 mA/4 to 20 mA
Input impedance: 250 Ω, Output load resistance: up to 600 Ω
Power supply24 V DC ±10%
Applicable standard
and EMC compatibility
RoHS
EMC standard: EN61326-1: 2006
