SFC3000
คุณสมบัติสินค้า:
หมวดหมู่ : INSTRUMENTS , TOKYO KEISO , Flow Measurement , Ultrasonic Flowmeters for Built-in Use ,
แบรนด์ : TOKYO KEISO
Share
Features
- Enhanced resistance to bubbles
- The converter is compact and lightweight with a plug-in construction easy for wiring.
- Cleared EMC test: EN61326-1: 2013 EN61326-2-3: 2013. RoHS compatible
- Liquids with kinematic viscosity of as high as 40 mm2/s can be measured
- Corrosion resistant and easy to install
- Accuracy: Within ±1% of the reading at flow velocity of 1 m/s or more
- Additional functions: Error detection, Self diagnosis
- Simple parameter setting suitable for each measuring liquid
Short Specifications
| Model | SFC3000 |
|---|---|
| Applicable detectors | UCUF-04BL, UCUF-04K/06K, UCUF04E/06E, UCUF-04M/06M UCUF-10K/15K/20K, UCUF-10M/15M/20M |
| Measuring fluid | Liquids |
| Fluid temperature | 5 to 90°C |
| Fluid sound speed | 400 to 2500 m/s |
| Fluid kinematic viscosity | 0.3 to 40mm²/s |
| Flow range | Min.: 0 to 0.05 L/min, Max.: 0 to 8.0 L/min |
| Input | Exclusive cable with a BNC connector from detector |
| Pulse output | Selectable from frequency pulse, totalizing pulse or fault output By open collector: Load rating: Within 30 VDC, 15 mA ·Frequency pulse output Duty ratio: 1:1 Pulse rate: 0 to 1000 Hz (full scale) ·Totalizing pulse output Unit x0.1 mL, x1 mL, x10 mL, x1L Pulse width: 0.5 ms, 50 ms, 100 ms ·Fault output when converter or detector is in error. NO or NC is selectable |
| Current output | 4 to 20 mA DC Load resistance: Within 500 Ω |
| Low flow cutoff | 0 to 25 %F.S. |
| Communication | RS485 communication function, Protocol: MODBUS Up to 32 units can be connected |
| Power supply | 24 VDC±10% |
| Enclosure | IP20 Indoor use |
| Installation | DIN rail installation |
